Offset Arms

In-Line & 90° Offset Arms

Features & Benefits

The In-line Offset Arms and the 90° Offset Arms provide a cost effective solution for simple 90° transitions or in-line offsets without the expense or added flexibility of our patented Swivel Clamp Assemblies.

  • Solid one piece machined aluminum for structural integrity.
  • Machined to close tolerance for maximum clamping force on standard bases, tooling arms and tooling links.
  • Ideal for a simple 90 degree offset or an in-line offset of standard bases to tooling arms or tooling arm to tooling arm transitions.
  • Independent adjustability in two axis.
  • Metric fasteners.
  • Anodized finish for appearance and durability.

Please click on the product details tab for a printable version of product specifications.

You might also be interested in some other tooling components like;  Standard Bases or Tooling Links.
